Move data between databases, CSV, and Excel with DbaClientX and PSWriteOffice

PowerShell is often the glue between systems that were never designed to talk to each other. A database stores operational data, CSV is the common machine-to-machine handoff, Excel is where people review and correct data, and sooner or later somebody needs reliable paths in both directions.

DbaClientX is a provider-neutral database client for PowerShell and .NET. It can query SQL Server, PostgreSQL, MySQL, Oracle, and SQLite, and it exposes provider-native bulk insert paths for tabular data.

PSWriteOffice creates and reads Office files from PowerShell. For this workflow, the important parts are Excel and CSV: export rows into real .xlsx workbooks or delimited text files, import reviewed data as PowerShell objects, DataTable, or IDataReader, and do it without requiring Microsoft Excel on the machine.

OfficeIMO is the engine underneath PSWriteOffice. It owns the workbook implementation so the PowerShell commands can stay concise while the same workflow scales from a quick export to explicit workbook composition.

The result is a practical data movement story:

• You want database rows in Excel? Query with DbaClientX, export with PSWriteOffice.
• You want a CSV handoff without turning every row into a PSCustomObject? Pass the same reader to Export-OfficeCsv.
• You want a reviewed workbook back in a database? Import with PSWriteOffice, bulk write with DbaClientX.
• You want to avoid materializing every row as a PowerShell object? Hand an IDataReader directly from the database client to the workbook writer.
• You want the flexible path? Use normal PowerShell objects and let the commands convert them.

Before you start

Use PowerShell 7 and install the public module versions used for this article:

Install-Module PSWriteOffice -RequiredVersion 3.0.7 -Scope CurrentUser
Import-Module PSWriteOffice -RequiredVersion 3.0.7
Install-Module DbaClientX -RequiredVersion 1.0.8 -Scope CurrentUser
Import-Module DbaClientX -RequiredVersion 1.0.8

Run examples from a working folder where you can write the generated files. Supply your own inputs wherever a later example references an existing file or service.

The credential examples also require Microsoft.PowerShell.SecretManagement and a registered vault provider. The final email example additionally uses Mailozaurr:

Install-Module Microsoft.PowerShell.SecretManagement -Scope CurrentUser
Install-Module Mailozaurr -Scope CurrentUser
Import-Module Microsoft.PowerShell.SecretManagement

Install and register the vault provider used by your environment, select its default vault, and store Operations-Database-Credential and Reporting-Smtp-Credential as PSCredential secrets before running those sections. Get-SecretVault lists registered vaults; Test-SecretVault -Name '<your-vault-name>' verifies access. Installing SecretManagement alone does not create a vault or populate either secret. Replace the example database, SMTP server, sender, and recipients with your own settings.

How this fits with dbatools and ImportExcel

This is not an argument that existing scripts need to move.

dbatools is an established SQL Server automation toolkit. If a job already uses its instance, backup, migration, or administrative commands, keeping data movement in that ecosystem may be the clearest choice. DbaClientX becomes interesting when the same provider-neutral data contract needs to work from PowerShell and .NET, or when a live reader should pass directly into another library.

ImportExcel is the familiar choice for many PowerShell-to-Excel scripts. If Export-Excel and Import-Excel already produce the workbook you need, there is no migration prize for changing them. PSWriteOffice is useful when the workbook is one part of a wider Word, PowerPoint, PDF, CSV, or document-inspection workflow, or when direct DataTable and IDataReader handoffs matter.

The modules also compose. You can keep dbatools for the surrounding SQL Server job, use ImportExcel for a workbook that already depends on it, and introduce DbaClientX or PSWriteOffice only where their public contracts solve a specific problem.

Connect to the database

For SQL Server with integrated security, let DbaClientX build the connection string:

$connectionString = New-DbaXConnectionString `
    -Provider SqlServer `
    -Server 'sql01' `
    -Database 'Operations' `
    -Ssl

For SQL Server with a credential, DbaClientX query cmdlets can accept -Credential:

$credential = Get-Credential

Invoke-DbaXQuery `
    -Server 'sql01' `
    -Database 'Operations' `
    -Credential $credential `
    -Query 'SELECT TOP 10 Id, Name, Status FROM dbo.WorkQueue'

For providers that require a database login, retrieve a PSCredential from your normal secret store and give it to the same builder:

$databaseCredential = Get-Secret -Name 'Operations-Database-Credential'

$postgresConnectionString = New-DbaXConnectionString `
    -Provider PostgreSql `
    -Server 'pg01' `
    -Database 'Operations' `
    -Credential $databaseCredential `
    -Ssl

SQLite needs no credential:

$sqliteConnectionString = New-DbaXConnectionString `
    -Provider SQLite `
    -Database '.\operations.db'

Get-Secret comes from Microsoft.PowerShell.SecretManagement. In CI, the credential or connection string can come from the runner's secret provider instead. The important boundary is that passwords do not live in the article, script, repository, or command history.

Export database rows to Excel

If you want a workbook that people can open, filter, review, and send back, query the database and export the result as an Excel table:

The editable round trip assumes dbo.WorkQueue has an externally assigned, non-IDENTITY Id primary key and a RowVersion column of SQL Server's rowversion type. New workbook rows must have unique IDs assigned by your application. Tables with database-generated identity keys need a separate insertion and key-mapping workflow. Export the concurrency token as hexadecimal text in ExpectedVersion, and keep it unchanged while editing Name and Status. A rowversion changes on every database update, so it detects changes without relying on timestamp precision surviving an Excel round trip. The import updates only rows whose editable values changed, preserving ModifiedUtc and the token for unchanged rows.

$databaseServer = 'sql01'
$databaseName = 'Operations'
$trustServerCertificate = $false

$connectionString = New-DbaXConnectionString `
    -Provider SqlServer `
    -Server $databaseServer `
    -Database $databaseName `
    -Ssl `
    -TrustServerCertificate:$trustServerCertificate

$reader = Invoke-DbaXQuery `
    -Server $databaseServer `
    -Database $databaseName `
    -TrustServerCertificate:$trustServerCertificate `
    -Query 'SELECT Id, Name, Status, ModifiedUtc, CONVERT(varchar(18), CAST(RowVersion AS binary(8)), 1) AS ExpectedVersion FROM dbo.WorkQueue' `
    -AsDataReader

try {
    Export-OfficeExcel `
        -InputObject $reader `
        -Path .\WorkQueue.xlsx `
        -WorksheetName 'Work Queue' `
        -TableName 'WorkQueue' `
        -AutoFit `
        -FreezeTopRow
} finally {
    $reader.Dispose()
}

The query uses DbaClientX's direct SQL Server parameter set, which enables encryption and applies the explicit certificate-trust decision. The generated connection string is kept for the streaming example and the later bulk-write path.

That produces a native .xlsx workbook, not a CSV renamed to Excel. The table can be filtered, formatted, and opened by Excel without requiring Excel on the machine that created it.

For smaller jobs, object pipelines are fine:

Invoke-DbaXQueryStream `
    -Provider SqlServer `
    -ConnectionString $connectionString `
    -Query 'SELECT Id, Name, Status FROM dbo.WorkQueue' |
    Export-OfficeExcel `
        -Path .\WorkQueue-Simple.xlsx `
        -WorksheetName 'Work Queue' `
        -TableName 'WorkQueue' `
        -AutoFit

That is the flexible path. It is easy to read and easy to extend with Where-Object, Select-Object, and calculated properties.

For a pass-through SQL Server export, the owned IDataReader above keeps the rows streaming until PSWriteOffice has consumed them. Dispose it in finally because the reader owns the live command and connection. Use DataTable instead when the script needs to inspect, validate, or reshape the complete dataset before writing the workbook.

Import Excel rows to a database table

When the first export comes back from review, import it as a DataTable and write it to a staging table. Existing rows retain their ExpectedVersion; an intentionally new row has a new Id and an empty ExpectedVersion. This example treats blank Name and Status cells as SQL NULL; adapt that rule if your schema requires non-null values or distinguishes empty strings from nulls:

$databaseServer = 'sql01'
$databaseName = 'Operations'
$trustServerCertificate = $false

$connectionString = New-DbaXConnectionString `
    -Provider SqlServer `
    -Server $databaseServer `
    -Database $databaseName `
    -Ssl `
    -TrustServerCertificate:$trustServerCertificate

$table = Import-OfficeExcel `
    -Path .\WorkQueue-Reviewed.xlsx `
    -WorksheetName 'Work Queue' `
    -AsDataTable

foreach ($column in 'Id', 'Name', 'Status', 'ExpectedVersion') {
    if (-not $table.Columns.Contains($column)) {
        throw "The reviewed workbook is missing the required '$column' column."
    }
}
foreach ($row in $table.Rows) {
    foreach ($column in 'Name', 'Status') {
        if ([string]::IsNullOrEmpty([string]$row[$column])) {
            $row[$column] = [DBNull]::Value
        }
    }
    $token = [string]$row.ExpectedVersion
    if ($token.Length -gt 0 -and $token -notmatch '^0x[0-9a-fA-F]{16}$') {
        throw "WorkQueue ID '$($row.Id)' has an invalid ExpectedVersion. Re-export it before reviewing."
    }
}

$duplicateIds = @($table.Rows | Group-Object Id | Where-Object Count -gt 1)
if ($duplicateIds.Count -gt 0) {
    throw "The workbook contains duplicate WorkQueue IDs: $($duplicateIds.Name -join ', ')."
}

$stageTable = 'dbo.WorkQueue_Stage_' + ([guid]::NewGuid()).ToString('N')

try {
    $writeResult = $table | Write-DbaXTableData `
        -Provider SqlServer `
        -ConnectionString $connectionString `
        -DestinationTable $stageTable `
        -AutoCreateTable `
        -BatchSize 5000 `
        -ErrorAction Stop `
        -PassThru

    $mergeResult = Invoke-DbaXNonQuery `
        -Server $databaseServer `
        -Database $databaseName `
        -TrustServerCertificate:$trustServerCertificate `
        -ErrorAction Stop `
        -Query @"
SET XACT_ABORT ON;
BEGIN TRY
    BEGIN TRANSACTION;

    IF EXISTS (
        SELECT 1
        FROM $stageTable AS source
        LEFT JOIN dbo.WorkQueue AS target WITH (UPDLOCK, HOLDLOCK)
            ON target.Id = source.Id
        WHERE (
            NULLIF(source.ExpectedVersion, '') IS NOT NULL
            AND (target.Id IS NULL
                OR target.RowVersion <> CONVERT(binary(8), source.ExpectedVersion, 1))
        ) OR (NULLIF(source.ExpectedVersion, '') IS NULL AND target.Id IS NOT NULL)
    )
        THROW 51000, 'The workbook conflicts with current WorkQueue rows. Re-export and resolve the conflicts.', 1;

    UPDATE target
    SET Name = source.Name,
        Status = source.Status,
        ModifiedUtc = SYSUTCDATETIME()
    FROM dbo.WorkQueue AS target
    JOIN $stageTable AS source ON target.Id = source.Id
    WHERE EXISTS (
        SELECT CONVERT(varbinary(max), CONVERT(nvarchar(max), target.Name)), CONVERT(varbinary(max), CONVERT(nvarchar(max), target.Status))
        EXCEPT
        SELECT CONVERT(varbinary(max), CONVERT(nvarchar(max), source.Name)), CONVERT(varbinary(max), CONVERT(nvarchar(max), source.Status))
    );

    INSERT dbo.WorkQueue (Id, Name, Status, ModifiedUtc)
    SELECT source.Id, source.Name, source.Status, SYSUTCDATETIME()
    FROM $stageTable AS source
    WHERE NOT EXISTS (SELECT 1 FROM dbo.WorkQueue AS target WHERE target.Id = source.Id);

    COMMIT TRANSACTION;
END TRY
BEGIN CATCH
    IF @@TRANCOUNT > 0 ROLLBACK TRANSACTION;
    THROW;
END CATCH;
"@

    [pscustomobject]@{
        StagedRows = $writeResult.Rows
        ChangedRows = $mergeResult
    }
} finally {
    $cleanupResult = Invoke-DbaXNonQuery `
        -Server $databaseServer `
        -Database $databaseName `
        -TrustServerCertificate:$trustServerCertificate `
        -Query "DROP TABLE IF EXISTS $stageTable;"
}

The important detail is -AsDataTable. That gives DbaClientX a tabular shape it can send to provider-native bulk insert APIs. The bulk writer uses the generated connection string; the merge and cleanup commands use the same server, database, and certificate-trust decision, and DbaClientX enables SQL Server encryption for those direct non-query connections. If the workflow uses a database credential, pass the same $databaseCredential to both New-DbaXConnectionString and Invoke-DbaXNonQuery.

A unique staging table isolates retries and concurrent imports; the finally block removes it even when validation or import fails. The transaction locks the relevant keys while comparing version tokens and applying changes. A changed or deleted source row, a newly occupied ID, or a retry of a workbook that already changed or inserted rows rejects the whole batch. Replaying a workbook that made no changes is a harmless no-op. Re-export and resolve those conflicts instead of overwriting newer values. Rows omitted from the workbook are left alone; this example does not perform deletions. Validate types, required values, row counts, duplicate keys, and business rules before changing production data.

Use the same ownership boundary for CSV

CSV does not need a second database client hidden inside file-format commands. DbaClientX can keep owning the query and connection lifetime while PSWriteOffice owns delimiters, quoting, encoding, compression, and the CSV artifact.

For database-to-CSV streaming, pass the live reader as one input object and dispose it after the writer finishes:

$reader = Invoke-DbaXQuery `
    -Server 'sql01' `
    -Database 'Operations' `
    -Query 'SELECT Id, Name, Status, ModifiedUtc FROM dbo.WorkQueue' `
    -AsDataReader

try {
    Export-OfficeCsv `
        -InputObject $reader `
        -Path .\WorkQueue.csv `
        -Delimiter ',' `
        -Encoding ([System.Text.UTF8Encoding]::new($false))
} finally {
    $reader.Dispose()
}

For CSV-to-database streaming, describe the important column types at the file boundary, then hand the resulting reader to DbaClientX as a single object:

$reader = Import-OfficeCsv `
    -Path .\ApprovedProducts.csv `
    -AsDataReader `
    -ColumnType @{
        ProductId = [int]
        UnitPrice = [decimal]
        Approved = [bool]
        ApprovedUtc = [datetime]
    }

try {
    Write-DbaXTableData `
        -Provider SqlServer `
        -ConnectionString $connectionString `
        -DestinationTable 'dbo.ApprovedProduct_Stage' `
        -InputObject (, $reader) `
        -BatchSize 5000
} finally {
    $reader.Dispose()
}

The leading comma in -InputObject (, $reader) is intentional: it prevents PowerShell from trying to enumerate the reader before DbaClientX receives it. For SQL Server, that reader can flow into the bulk-copy path without first becoming a full in-memory object array. For providers whose bulk API needs a materialized table, DbaClientX performs the provider-specific handoff.

Use -InferSchema when a representative sample is good enough, or -ColumnType when the staging contract is known. Explicit types are usually the safer choice for IDs, money, booleans, and timestamps. PSWriteOffice also exposes compressed CSV, null values, date formats, duplicate-header policy, strict or lenient quote handling, decompression limits, and parse-error behavior; those remain file-format concerns instead of becoming provider-specific switches in DbaClientX.

This composition is also why four extra commands such as Export-DbaXQueryCsv or Import-DbaXCsv would add little. The two modules already meet at standard .NET tabular contracts, and keeping that seam visible lets each one remain useful on its own.

Write directly only for append-only rows

Sometimes the workbook contains guaranteed-new rows for an append-only import log. In that narrow case, writing directly to the destination table can be acceptable:

$table = Import-OfficeExcel `
    -Path .\ApprovedProducts.xlsx `
    -WorksheetName 'Products' `
    -AsDataTable

$table | Write-DbaXTableData `
    -Provider SqlServer `
    -ConnectionString $connectionString `
    -DestinationTable 'dbo.ProductImportLog' `
    -BatchSize 10000 `
    -BulkCopyTimeout 120

Validation alone does not make a direct bulk write repeatable. If the workbook can contain an existing key, replace a row, or be retried, use the isolated staging-and-merge workflow instead. Direct writes are for rows whose keys are guaranteed to be new and whose destination is intentionally append-only.

Use the same shape for other providers

The same command shape can target other providers by changing the provider and connection string:

$customers = Import-OfficeExcel `
    -Path .\Customers.xlsx `
    -WorksheetName Customers `
    -AsDataTable

$customers | Write-DbaXTableData `
    -Provider PostgreSql `
    -ConnectionString $postgresConnectionString `
    -DestinationTable 'public.customer_stage' `
    -BatchSize 5000

SQLite is useful for local tools, test fixtures, and portable handoff files:

$audit = Import-OfficeExcel `
    -Path .\Audit.xlsx `
    -WorksheetName Events `
    -AsDataTable

$audit | Write-DbaXTableData `
    -Provider SQLite `
    -ConnectionString $sqliteConnectionString `
    -DestinationTable 'audit_events' `
    -BatchSize 1000

For SQL Server, PostgreSQL, MySQL, Oracle, and SQLite, the workflow stays the same: import or build tabular data, choose the provider, give DbaClientX the connection string, and write to the target table.

Pick the shape that fits the job

Choose between PowerShell objects, an in-memory DataTable, and a streaming IDataReader according to the transformations and buffering the job needs.

Use the flexible path when the dataset is small or you need PowerShell transformations:

Invoke-DbaXQuery -Server 'sql01' -Database 'Operations' -Query 'SELECT Id, Status FROM dbo.WorkQueue' |
    Where-Object Status -ne 'Closed' |
    Select-Object Id, Status, @{ Name = 'ExportedUtc'; Expression = { [DateTime]::UtcNow } } |
    Export-OfficeExcel -Path .\OpenWork.xlsx -WorksheetName Open -TableName OpenWork

Use a buffered tabular path when the script needs the whole result for validation or transformation:

$rows = Invoke-DbaXQuery `
    -Server 'sql01' `
    -Database 'Operations' `
    -Query 'SELECT Id, Status, ModifiedUtc FROM dbo.WorkQueue' `
    -ReturnType DataTable

Export-OfficeExcel `
    -InputObject $rows `
    -Path .\WorkQueue.xlsx `
    -WorksheetName 'Work Queue' `
    -TableName 'WorkQueue' `
    -AutoFit

The commands still look like normal PowerShell, but the data stays in a form that database and workbook libraries understand directly. When the rows only need to pass through, use the IDataReader example from the export section to avoid buffering the complete result.

What the benchmarks actually measure

We built these paths while trying to shorten our own reporting jobs, but the useful question is not which module wins in the abstract. It is whether the exact job is equivalent, the output is correct, and the result repeats on the machine that will run it.

The DbaClientX benchmark snapshot includes PowerForge suites for direct SQL Server reads and writes. In that committed 25,000-row snapshot, the comparable DataTable lanes reported these medians:

Those are client-side data-movement lanes, not a comparison of the much broader dbatools command set. The runner seeds isolated tables outside the measurement and validates row counts plus identifier and score sums afterward.

A separate dated run on 10 August 2026 measured the complete 25,000-row SQL Server to XLSX to SQL Server job. The DbaClientX lane streamed through PSWriteOffice and OfficeIMO; the comparison used ImportExcel 7.8.10 through its public object pipeline. Both produced the same table contract and passed strict SQL-side row, schema, and value checks.

The two columns are deliberate. This workstation uses an AMD Ryzen 9 9950X3D2 with two performance domains, so the full comparison was repeated with one 16-logical-processor affinity mask at a time. The run used PowerShell 7.6.4, SQL Server 17.0.1125.2, High process priority, five warmups, fifteen rotated measured iterations, and no removed outliers. All 60 measured round trips passed validation.

The gap is meaningful for that source-linked fixture; it is not a promise that every workbook, database, CPU, or module version will produce the same ratio. Read the SQL Server benchmark notes at the measured revision, keep both processor domains visible on heterogeneous machines, and rerun the matrix with the row shape and workbook features used in production.

Publish The Review Pack

A database export often needs two forms: an editable workbook for analysts and a fixed-layout copy for approval or archival. PSWriteOffice can create the workbook and explicitly export it to PDF; Mailozaurr can then deliver both without making the data-access script own SMTP:

Import-Module Mailozaurr

$outputDirectory = (New-Item -ItemType Directory -Path (Join-Path (Get-Location).Path 'Output') -Force).FullName
$workbookPath = Join-Path $outputDirectory 'WorkQueue.xlsx'
$pdfPath = Join-Path $outputDirectory 'WorkQueue.pdf'

$rows = Invoke-DbaXQuery `
    -Server 'sql01' `
    -Database 'Operations' `
    -Query 'SELECT Id, Name, Status, ModifiedUtc, CONVERT(varchar(18), CAST(RowVersion AS binary(8)), 1) AS ExpectedVersion FROM dbo.WorkQueue' `
    -ReturnType DataTable

Export-OfficeExcel `
    -InputObject $rows `
    -Path $workbookPath `
    -WorksheetName 'Work Queue' `
    -TableName WorkQueue `
    -AutoFit `
    -FreezeTopRow

Export-OfficeDocumentPdf `
    -InputPath $workbookPath `
    -Path $pdfPath

$mailCredential = Get-Secret -Name 'Reporting-Smtp-Credential'
Send-EmailMessage `
    -From 'reports@example.com' `
    -To 'reviewers@example.com' `
    -Subject 'Work queue review pack' `
    -Text 'The editable workbook and PDF review copy are attached.' `
    -Attachment $workbookPath, $pdfPath `
    -Server 'smtp.example.com' `
    -Credential $mailCredential `
    -UseSsl

InputPath is intentional on Export-OfficeDocumentPdf because Path names the PDF being produced. Elsewhere, PSWriteOffice uses Path for the primary file, OutputPath for a transformed copy, and DestinationPath for a copy destination.

The ownership stays simple: DbaClientX queries and writes database data, PSWriteOffice creates document artifacts, and Mailozaurr handles credentials, message transport, and attachments. Get-Secret comes from Microsoft.PowerShell.SecretManagement; use the same secret provider your scheduled job or CI runner already trusts.

Common scenarios

This pattern fits a lot of everyday operational work:

• Use compact CSV for machine handoffs and real Excel workbooks for human review.
• Export SQL Server review queues to business owners.
• Load reviewed workbook changes into staging tables.
• Build audit handoff workbooks from PostgreSQL, MySQL, Oracle, SQLite, or SQL Server.
• Use SQLite as a local database for workbook-driven tools.
• Keep import/export scripts reusable instead of rewriting them per report.

The short version:

# Database to Excel
$rows = Invoke-DbaXQuery ... -ReturnType DataTable
Export-OfficeExcel -InputObject $rows -Path .\Data.xlsx -WorksheetName Data -TableName Data

# Database to CSV without object materialization
$reader = Invoke-DbaXQuery ... -AsDataReader
try { Export-OfficeCsv -InputObject $reader -Path .\Data.csv } finally { $reader.Dispose() }

# Excel to database
$table = Import-OfficeExcel -Path .\Data.xlsx -WorksheetName Data -AsDataTable
$table | Write-DbaXTableData -Provider SqlServer -ConnectionString $connectionString -DestinationTable dbo.Data_Stage

That is the workflow: query, export, review where needed, import, bulk write, validate, merge.
